Mixed Metal Oxide (MMO/MMH), is blend of complex chemicals fundamentally different from conventional chemicals. MMO/MMH is chemically reacted blend of Oxides and Hydroxides of Aluminum and Magnesium. MMO/MMH acts as bentonite extender to maximize carrying capacity in water based drilling fluid.
The rheological profile of mud is obtained using six speed viscometer, mud containing MMH has shown to provide relatively high 3 rpm and 6 rpm readings vis-à-vis, 300 rpm and 600 rpm reading. Hence, by design MMO/MMH produces relatively high rheological values without impacting the gel strength, thus resulting in lower energy requirement to initiate circulation. Thus MMO/MMH helps in providing higher gel strength when in motion while being relatively thinner when in motion.
Soil conditions such as Gravel or Cobble require high Gel Strengths in suspending and carrying out cutting. Especially in directional drilling the suspension and removal of cutting is far more troublesome which is where MMO/MMH helps in the cause. Bentonite-MMO/MMH drilling fluids can create very high gel strengths in order to suspend heavy drilling cuttings. Faster the bentonite drilling fluid moves thinner it gets (viscosity of drilling fluid changes with shear instead of temperature) and when at rest bentonite drilling fluids for a gel like structure that prevents drill cuttings from settling. MMO/MMH drilling fluid additionally accentuates this principle of Bentonite drilling fluids and takes the application to extreme.
ADVANTAGES
- Reduced mud losses in natural fractures.
- Helps in healing for induced fractures from excessive pressures.
- Effectively reduces mud loss while drilling.
- High Temp stability 300 – 400 F.
- Compatible with Anionic Polymers.
- Upto 60% lower usage of bentonite.
- Shear thinning helps enhanced ROP.
APPEARANCE : White/off white free flowing powder.
BULK DENSITY 1.0-1.1 gm/CC.
ODOR Oderless.
pH 1% Solution 9.5-10.5.
USES
- Produces high viscosity at low shear rates.
- For conventional, angled & horizontal wells.
- Economical replacement for Xanthan Gum, when using fresh water, salt water or SSW fluids.
- Excellent for Sea water and SSW fluids.
- Superior hole cleaning in fresh water mud.
- Reduced fluid losses in highly permeable, depleted & unconsolidated sand and gravels.
- To be used in area where conventional LCM and specialize blending remedies are not effective in controlling losses.
Fresh Water :: For 5-8 ppb of Standard API quality bentonite, dosage of MMO/MMH in range of 0.65 – 0.775 ppb through conventional hopper as needed to control Viscosity, YP & Rheology.
Sea Water :: Pre-mix 25-30ppb non-treated API bentonite in fresh water, with ½ ppb soda ash, diluted with sea-water or bleed into circulating mud volume.
Note :: pH of circulating fluid to be maintained between 10.3 – 10.5 for optimum results.
